Modulating Gas Burner TBG-35 MC (410 KW) LPGNatural

• Fuel Natural Gas / LPG
• Operation Mechanical Modulation
• Minimum Thermal Power 80 KW
• Maximum Thermal Power 410 KW
• Min flow rate (Smïï/H) 8 (NG) / 5.80 kg/h (LPG)
• Max flow rate (Smïï/H) 43 (NG) / 29.76 kg/h (LPG)
• Electric power supply type AC/ 1 phase/ 230V/ 50 Hz
• Fan Motor Power (kW) 0.4
• Weight without packaging (kg) 29
• Weight with packaging (kg) 31
• Width (mm) 980
• Depth (mm) 540
• Height (mm) 480

• Gas burner compliant with European standard EN676. Electronic operation at two progressive stages.
• Continuous modulation operation by installing P.I.D. controller in the control panel (to be ordered separately with modulation probe).
• Modulation ratio 1:5
• Gas burner with low NOx and CO emissions in accordance with European standard EN676: class 3.
• Regulating combustion air and blast-pipe.
• Combustion air intake with throttle damper. Air flow adjustment with mechanical cam.
• Fully closing air damper on shutdown to avoid loss of heat through the chimney.
• Maintenance facilitated by the possibility of removing the combustion head without having to remove the burner from the boiler.
• Sliding boiler coupling flange to adapt the blast-pipe to the various types of boilers.
• CE version gas train is complete with butterfly valve, operation and safety valve with electromagnetic drive, minimum pressure switch, pressure regulator and gas filter.
• Possibility to choose gas train with valve tightness control.
• Fail proof connectors for burner/gas train connection
• Gas train exit: low.
• Flame detection by ionisation electrode with connector for micro amp meter.
• 7-pole socket for burner electric and thermostatic supply.
• 4-pole socket for second stage control or for the connection of the PID electronic regulator.
